OCTO 250 Tower

content_octo250logoOCTO 250 Aluminium Tower has been carefully designed to use a unique ‘climbing frame’ design, featuring 8 non-slip rungs at 250mm centres on a full size 2.0m frame and up to 7 smaller sized frames. This means that it is possible to have more working heights than any other alternative scaffold tower systems. This is very beneficial when working with height restrictions.

OCTO 250 Tower has a unique frame design with conical head spigots, ensuring a quick, easy and safe connection of frames, without the need for pins or clips. This helps prevent the jamming of frames and avoidable costly rung damage.

Category:

Product Description

OCTO 250 Tower is of the highest health and safety standard and adheres to the working at height act of 2005. It can be built using the 3T or advanced guardrail methods, which are the only PASMA approved methods of building tower scaffold.

The Octo 250 System is comprised of the following main components that determine the dimensions of the height, width and length of every Tower Scaffold.

Double Width Tower
A wider frame with two Platforms side by side creates a larger working space with more stability, which is essential when working at height. Platform lengths can be 1.5m, 2.5m or 3.2m for an extra long tower.

Description Height Width
8 Rung Frame 2.0m 1.5m
6 Rung Frame 1.5m 1.5m
4 Rung Frame 1.0m 1.5m

Single Width Tower
Can only accommodate a single platform and is essential if space is an issue, whether it is because of lack of floor space, obstructions or limited transportation space. The length of the platform can vary depending on which platform size is used.

Description Height Width
8 Rung Frame 2.0m 0.9m
6 Rung Frame 1.5m 0.9m
4 Rung Frame 1.0m 0.9m

There are alternative sized frames for more precise tower heights, especially if you have a restricted working height, but the frames listed above are standard and are used on the vast majority of applications.

Platform Sizes

Description Height Width
1.5m Platform 1.5m 0.6m
2.5m Platform 2.5m 0.6m
3.2m Platform 3.2m 0.6m

Stop-Nocs

This unique simple but effective fire retardant product can be used in numerous environments, reducing the risk of accidental damage by absorbing the force of impact made by Access equipment. Find out more, click here.

Downloads

  • For more information on this product, click here to view or download our product guide.
  • Click here to view or download the Octo 250 instruction manual.
